Hawkeye V3 HD Video Borescopes
HD Quality Photos & Videos, Wi-Fi Remote Viewing and More!
Hawkeye® V3 HD Video Borescopes simply deliver the best image quality of any borescope on the market today! The V3 HD features a new Micro HD video camera, and custom-engineered image processor. The 4 and 6 mm Hawkeye V3s capture HD video footage and still images that are crystal clear with vibrant, lifelike colors.
|  |
  | Building on the popular Hawkeye V2 Video Borescope, which was launched in 2012, the new Hawkeye V3 incorporates significant technological advancements, and represents the next generation of video borescopes designed and manufactured by Gradient Lens Corporation. The V3 also incorporates a large, 5.5-inch HD, daylight readable, touch-screen display. The V3 easily displays, captures, and transmits over WiFi, crystal clear High-Definition (HD) video and still images, and does so using a sleek, ergonomic design, superior construction, and intuitive user interface. The Hawkeye V3 is a valuable tool for numerous manufacturing quality control applications - in the QC Lab and on the shop floor. The V3 is also an essential tool for aircraft, and power generation, windpower, and engine and systems maintenance teams. The fully portable V3 provides fast, accurate diagnostics, in mission-critical situations, without the need for costly, time-consuming engine teardown. Interchangeable 90-degree and close-focus optical tips are optional. The smooth servo-driven articulation range is +/- 180 degrees. The V3 can operate continuously for 5 hours without the need for recharging. The V3 contains an integrated, high-efficiency Micro LED light source. |
Hawkeye V3 Video Borescopes Specifications:
| Diameter | 4.0 or 6.1 mm (0.16” or 0.24”) |
| Lengths | 1.5, 3.0, 6.0 and 8.0 meters (4.92', 9.84', 19.69' and 26.25') |
| Articulation | 1.5 - 3.0 m length (4.92' - 9.84') +/-160º min 6 m length (19.69') +/-140º min 8 m length (26.25') +/-120ºmin Articulation tolerance will be +10º - 0º |
| Field-of-View | 70º Diagonal |
| Depth-of-Field | 18 mm - ∞ (0.71” - ∞) |
| Depth-of-Field w/ CF Tip | 6 - 25 mm (0.19” - 0.98”) |
| Direction-of-View | 0º, 90º with optional Prism Tip |
| Sheath | 2 mil Tungsten Braid, durable 4-layer construction |
| Camera | 1280 x 720p CMOS |
| Display | 5.5” HD, High Brightness, Daylight Readable |
| Interfaces | HDMI, USB 2.0 flash memory, USB mini B for computer interface, 3.5 mm headset /mic jack |
| Power | AC input: 100 - 240 VAC, 50 - 60 Hz, 1.5 A Max DC Output: 24V, 2.5A |
| Battery | 5 hr. run time, 14.4V, 92 Wh Lithium Ion |
| Recording Media | USB Thumb Drive |
| Digital Photo Format | JPEG |
| Video Format | MPEG 4 |
| Operating Temp. Range | Tip: -25º to +100º C (-13º to +212º F) Display Unit: -20º to +46º C (-4º to +115º F) |
| Storage Temp. Range | -25º to +60º C (-13º to +140º F) |
| Weight | 5.4 lbs. (2.45 kg) |
V3 Standard Kit Includes: Videoscope, Carrying Case, Battery, Charger
V3 Deluxe Kit Includes: Videoscope, Carrying Case, 90° Prism Tip, Close-Focus Tip, Rigidizer, Stand, Neck Strap, Spare Battery
Hawkeye V3 HD Video Borescopes - Standard Kits:
| Diameter | Length | Articulation | Sheath | Model # |
| 4mm | 1.5m (4'11") | 4-way | Tungsten | RV-HG-V3-040-1500-4 |
| 4mm | 3.0m (9'10") | 4-way | Tungsten | RV-HG-V3-040-3000-4 |
| 6mm | 3.0m (9'10") | 4-way | Tungsten | RV-HG-V3-060-3000-4 |
| 6mm | 1.5m (4'11") | 4-way | Tungsten | RV-HG-V3-060-1500-4 |
| 6mm | 6.0m (19'8") | 4-way | Tungsten | RV-HG-V3-060-6000-4 |
| 6mm | 8.0m (26'3") | 4-way | Tungsten | RV-HG-V3-060-8000-4 |
Hawkeye V3 HD Video Borescopes - Deluxe Kits
| Diameter | Length | Articulation | Sheath | Model # |
| 4mm | 1.5m (4'11") | 4-way | Tungsten | RV-HG-V3D-040-1500-4 |
| 4mm | 3.0m (9'10") | 4-way | Tungsten | RV-HG-V3D-040-3000-4 |
| 6mm | 1.5m (4'11") | 4-way | Tungsten | RV-HG-V3D-060-1500-4 |
| 6mm | 3.0m (9'10") | 4-way | Tungsten | RV-HG-V3D-060-3000-4 |
| 6mm | 6.0m (19'8") | 4-way | Tungsten | RV-HG-V3D-060-6000-4 |
| 6mm | 8.0m (26'3") | 4-way | Tungsten | RV-HG-V3D-060-8000-4 |
Hawkeye V3 HD Video Borescope Accessories:
| Accessory | Model # |
| Close-Focus Tip - 4mm | RV-HG-V3-TIP-4CF |
| Close-Focus Tip - 6mm | RV-HG-V3-TIP-6CF |
| 90° Prism Tip - 4mm | RV-HG-V3-PTIP-4-90 |
| 90° Prism Tip - 6mm | RV-HG-V3-PTIP-6-90 |
| V3 Rigidizer (17" Length) - 4mm | RV-HG-V3-RT4 |
| V3 Rigidizer (17" Length) - 6mm | RV-HG-V3-RT6 |
| V3 Stand | RV-HG-V3-STAND |
| V3 Battery | RV-HG-V3-BATT |
| V3 Neck Strap | RV-HG-V3-STRAP |
| V3 Battery Charger | RV-HG-V3-CHARGER |
