160,000 Cd/m2, Reads 4.2 Density Film, Corrosion Resistant, High Quality

True 14" x 17" Viewing Screen

The Kowolux X 14x17 is a high-end film viewer with a true 14" x 17" viewing screen featuring a luminance of 160,000 Cd/m2 . Designed for evaluation of large format X-ray films with high optical density from castings and other complex parts and components. Powerful LEDs and a variety of accessories makes this indestructible, German made film viewer easy to use with a range of films.

Key Differences:

  • 14" x 17" Large Format
  • For High Density Films up to 4.2 D







Features

  • Large Format 14" x 17" Viewing Screen for a variety of films
  • 160,000 Cd/m2 Intensity
  • Corrosion resistant, strong and high quality stainless steel housing
  • Viewing screen is made of crystal glass with 95% translucency and an anti-reflective coating, which is thermally cured
  • Plug-in foot switch – plug screw-secured – operable without foot switch (with optional operation plug)
  • Two controls for brightness - 1%-100%
  • Efficient LEDs - Heat generation and power consumption is reduced by 80% compared to Halogen lamps and is more cost effective with a 40,000 hour lifespan
  • Higher contrast helps inspection personnel to find defects and discontinuities easily without vision fatigue and high luminance makes it possible to view very dark films without destroying them
  • Cooling fan with temperature dependent speed control - low noise level
  • Changeable filter in the cooling air in-let
  • Interchangeable masks for different film sizes
  • Mounting threads in side panels – for mounting loading device for roll films or a densitometer holder
  • Mounting threads in bottom panel – for safe fixing of the viewer on a desk in mobile laboratories

Kowolux X Model Comparison Chart

Model Viewing Screen Luminance Film Density Main Use Special Features
X3 3.2" x 17.8"

320,000 Cd/m2

Eco: 200,000 Cd/m2

 4.5 D
Eco: 4.3 D		 Weld Seam Images Durable, Perfect for Long Films, Many Attachments
X4 3.2" x 8.9"

320,000 Cd/m2

Eco: 200,000 Cd/m2

 4.5 D
Eco: 4.3 D		 Weld Seam Images Durable, Many Attachments
X5 4.3" x 6" 630,000 Cd/m2 4.8 D Turbine Blade Images, High Densities Durable, Many Attachments
X6 10.6" x 15”

200,000 Cd/m2

Eco: 130,000 Cd/m2

 4.3 D
Eco: 4.1 D		 Large Format Images Durable, Many Attachments
X7 Ø 4 - 75mm (0.16" - 3") - Iris 1,100,000 Cd/m2 5.0 D Universal, Highest Densities Built in Iris, Ultra-High Intensity, Durable
X 14x17" 14" x 17" 160,000 Cd/m2 4.2 D Large Format Images True 14" x 17" Viewing Window, Durable
LX40 17" x 17" 80,000 Cd/m2 3.9 D Large Format Images Built in Horizontal and Vertical Shutters, Durable
LX60 17" x 23" 80,000 Cd/m2 3.9 D Large Format Images Built in Horizontal and Vertical Shutters, Durable
M1 3.2" x 9" 150,000 Cd/m2 4.15 D Weld Seam Images Dust Proof & Moisture Resistant, Durable
M2 3.2" x 18" 150,000 Cd/m2 4.15 D Weld Seam Images Dust Proof & Moisture Resistant, Durable

Technical Specifications

Kowolux X 14x17

Luminance Max* 160,000 Cd/m2
Film Density Max** 4.2 D
Power Supply 88-264 VAC / 47-63 Hz
Viewing Screen 14" x 17" (430 × 355 mm)
Rated Power 600 W
Dimensions (WxDxH) 20.9" x 12.6" x 17.3" (530 x 320 x 440 mm)
Weight 57.3 lbs. (26 kg)
Color Temperature 5,000 K - White
Lamp Life 40,000 hours

*Luminance  approximately 10% higher than specified when delivered

**according to DIN EN 25580, ISO 5582 and ASTM E1390 maximum evaluable density

Optional Accessories

Optional Accessories for Kowolux X 14x17

Accessory Item X 14x17
Universal Densitometer Holder RT-KT-13-40087
Kowospool Spooling Device for Roll Films RT-KT-13-40088
Masks
14" x 17", 35.5 x 43.2 cm RT-KT-13-40661
7" x 17", 17.8 x 43.2 cm RT-KT-13-40662
8" x 10", 20.3 x 25.4 cm RT-KT-13-40663
5" x 7", 12.7 x 17.8 cm RT-KT-13-40664



Need a High Intensity Spot with Adjustable Iris?

You can simply convert the Kowolux X 14x17 into a high intensity spot viewer with the addition of a 10 x 4 X3 ancillary mask - Iris combo

Scope of Supply

  • Standard Attachment Mask
  • Power Cord
  • Foot Switch
  • Test Certificate according to ASTM E 1390, ISO 5580 & DIN EN 25580
  • Certificate of Conformance according to ISO/IEC 17050-1

Optional Accessories are Available Upon Request.

Click Here for More Information
