NDT 87-C1 Spot Film Viewer
The Model 87-C1 is a truly portable industrial radiographic film viewer with high intensity output
Features:
- Bright enough to view 3.7 Density Film using the included BAH 300-watt photoflood type bulb
- Constructed from electro-galvanized steel and painted with a durable polyurethane enamel
- Variable dimmer allows precise control of the light source for positive film interpretation.
- Variable light intensity control
- Fan cooled for prolonged operation
- Convenient carrying handle
- 5.25" x 4.75" glass view screen
- 300 watt lamp
- Face plate will accept optional iris diaphragm
- Convenient cord wrap for transport and storage ease
- Optional Footswitch control
Specifications:
| Dimensions (Width x Height x Depth): | 6" x 11" x 11" (152 x 279 x 279 mm) |
| Active Viewing Screen: | 5.25" x 4.75" (133 x 121 mm) |
| Weight: | 10 lbs (4.5 kg) |
| Shipping Weight: | 12 lbs. (5.4 kg) |
| Power Requirements: | 115 VAC, 50 - 60Hz |
Standard 87-C1 Spot Film Viewer includes:
- 87-C1 Film Viewer
- 8 foot power cord
Optional Accessories:
- 65-M4 Foot Switch with cable and plug
- 65-D4 Iris Diaphragm - 4" (102mm) round adjustable opening for high spot masking.
