The XRS3 has been replaced by the XRS3 GFX.
Same great qualities as the original XRS3 with an all-new graphics display.
The XRS3 GFX is a 270 kV, battery powered, pulsed X-ray generator used in security and light industrial applications. The XRS3 GFX is the most versatile unit because it provides exceptional penetrating ability, up to 1" of steel when used with various digital imaging systems, in a compact package. The compact design features a battery pack, sturdy glass tube, high voltage head and electronic controls in a single package that weighs less than 20 pounds. Spare battery packs are easy to come by because the XRS3 GFX is powered by the same commercially available battery packs that power DeWalt cordless tools. The XRS3 GFX shares the same electronic controls and battery as the XR200 GFX which enhances the versatility of both models.
It can withstand extreme environments including arctic and desert conditions. The XRS3 GFX is compatible with numerous digital imaging systems to make a powerful and highly portable X-ray system.
| Power: | DeWalt 20V Li-Ion Battery |
| Dimensions (with battery, Picatinny Rails and no key) | 15.42" x 4.26" x 5.83" (39.17 x 10.82 x 17.91 cm) |
| Weight: | 11.8 lbs. (5.4 kg) including battery |
| Output Dose: | 3 mR/pulse measured 12" from source |
| Pulse Rate: | 21 pulses per second |
| Pulses per Battery Charge: | 5500 |
| Source Size: | 1/8" (3mm) |
| Max. Photon Energy: | 270 kVp |
| Pulse Width: | 25 nanoseconds |
| Beam Angle: | 40 degree standard |
| Current Draw: | 20 amps |
| Max Duty Cycle: | 200 pulses per 4 minutes |
| Warm Up: | None Required |
| Operating Temperature: | -4° to 158°F (-20° to 70°C) |
| IP Rating | IP 54 |
| Warranty: | 1 yr. limited parts, labor, service |
| Item Description | Part # |
| XRS3 X-RAY SOURCE GFX 20V 7PK | 1350200 |
| XRS3 X-RAY 20V GFX KIT 110V: NO CASE (SOURCE, 2 - 20V BATTERIES, 110V CHARGER) | 1330210 |
| XRS3 X-RAY 20V GFX KIT 220V: NO CASE (SOURCE, 2 - 20V BATTERIES, 220V CHARGER) | 1330220 |
| XRS3 X-RAY 20V GFX KIT 110V: CABLE & CASE (SOURCE, 2 - 20V BATTERIES, 110V CHARGER, CABLE & CASE) | 1330230 |
| XRS3 X-RAY 20V GFX KIT 220V: CABLE & CASE (SOURCE, 2 - 20V BATTERIES, 220V CHARGER, CABLE & CASE) | 1330240 |
| XRS3 X-RAY 20V GFX KIT: CABLE & CASE (SOURCE, CABLE & CASE) | 1330260 |
| XRS3 X-RAY 20V GFX KIT 110V: CASE NO REMOTE CABLE (SOURCE, 2 - 20V BATTERIES, 110V CHARGER, ADAPTER CABLE & CASE) | 1330265 |
| XRS3 X-RAY 20V GFX KIT 220V: CASE NO REMOTE CABLE (SOURCE, 2 - 20V BATTERIES, 220V CHARGER, ADAPTER CABLE & CASE) | 1330266 |
| Item Description | Part # |
| BATTERY DeWalt® 20V 2 Ah Li-Ion SLIDE ON | 1800106 |
| BATTERY CHARGER DeWalt® 12V-20V SLIDE-ON 110V | 1800151 |
| BATTERY CHARGER DeWalt® 12V-20V SLIDE-ON 220V | 1800164 |
| REMOTE CABLE ASM 7PK (7 PIN K SERIES LEMO) | 1809030 |
| REMOTE CABLE ASM 5PK (5 PIN K SERIES LEMO) | 1809022 |
| REMOTE CABLE ASM 5PB (5 PIN B SERIES LEMO) | 1809013 |
| REMOTE CABLE ASM 7PK NO DELAY (7 PIN K SERIES LEMO) | 1809035 |
| REMOTE CABLE ASM 5PK NO DELAY (5 PIN K SERIES LEMO) | 1809027 |
| REMOTE CABLE ASM 5PB NO DELAY (5 PIN B SERIES LEMO) | 1809016 |
| TRIPOD MOUNT (20V XR200, XRS3) | 4000352 |
| TRIPOD KIT STANDARD FOR XR200, XRS3, XRS3RA | 1803040 |
| XRS3 SNAP ON LEAD COLLIMATOR CAP 20 degree | 1800281 |
| XRS3 SNAP ON LEAD COLLIMATOR CAP 30 degree | 1800282 |
| XRS3 SNAP ON LEAD COLLIMATOR CAP Rectangle | 1800283 |
| 10 MIL SNAP ON COPPER FILTER (XR150, XR200, XRS3) | 1800210 |
| 30 MIL SNAP ON COPPER FILTER (XR150, XR200, XRS3) | 1800230 |
| 40 MIL SNAP ON COPPER FILTER (XR150, XR200, XRS3) | 1800240 |
| 60 MIL SNAP ON COPPER FILTER (XR150, XR200, XRS3) | 1800260 |
| LEAD COLLIMATOR CAP SOLID (XR150, XR200, XRS3) | 1800265 |
| XRS3 Collimator Set Snap-on Lead Caps & Copper Filters (7 pcs) | 1800280 |
| LASER POINTER XRS3 | 1800303 |
| XRS3 / XRS4 TUBE REPLACEMENT KIT | 1000005 |
| XRS3 / XRS4 SPARE TUBE | 2200000 |
| BOTTLE OF DIALA OIL XRS3 & XRS4 TUBE REPLACEMENT | 8401000 |
| XRS3 COLLIMATOR ASM 40 DEGREE | 2600010 |
| XRS3 COLLIMATOR ASM 60 DEGREE | 2600020 |
| XRS3 COLLIMATOR ASM 85 DEGREE | 2600030 |
| XRS3 14V TO 20V GFX DISPLAY UPGRADE W/ ADAPTER CABLE | 9901531 |
| XRS3 18V TO 20V GFX DISPLAY UPGRADE W/ ADAPTER CABLE | 9901532 |
| XRS3 20V to GFX DISPLAY UPGRADE | 9901533 |
