Battery Powered Yoke Kit

Electro-Spect ES-X-BP Battery Powered Yoke Specification Sheet

Features:

Weight: 7.23 lbs.
Leg Span: 0” – 12”
Yoke Current Draw: 1.6 Amps in Air / 1.3 Amps on Test Block @ 6 Volts
Lift Test: 50 lbs.
Cord Length: Coiled = 3 ft. / Extended = 12 ft.
Duty Cycle: 30 seconds on / 30 seconds off
Battery Life: Approx. 6 Hours as tested / Undetermined in the field
Warranty: 1 Year

Battery Specifications:

6 Volt, 14 Amp Hour
Sealed Lead Acid (AGM)
5.26 lbs.
4.26 x 2.75 x 5.54
Output Current: 1.65 Amps Max
Output Voltage at full charge: 6.78 Volts
Charger Specifications: Auto Wall Charger
Output Voltage: 9.40 Volts DC @ 115v AC
Current Draw: 1 Amp @ 115 Volts AC

Kit Contents

19" metal tool box
ES-X/DC Ferrous Probe / with 3' coiled cord - (12' extended)
SLA- Re-chargeable 6 volt 14 amp hour battery
Battery carrying case with adjustable shoulder strap and belt loop
Switch Mode 6 volt Battery Charger 115v/220v
2-pounds #61 Gray magnetic powder
Powder bulb
Powder blower bulb
Nissen paint marker (yellow)
