Ray-Check IQI Sets
All Kits include hard wood case
Specifications:
ASTM-E-1742:
- Set “A” consists of 25 I.Q.I.'s and contains the following sizes: .25 , .31, .37, .43, .50, .56, .62, .68, .75, .81, .87, .93, 1.0, 1.1, 1.2, 1.3, 1.5, 1.6, 1.7, 1.8, 2.0, 2.1, 2.2, 2.3, 2.5
- Set “B” consists of 11 I.Q.I.'s and contains the following sizes: 2.7, 3.0, 3.2, 3.5, 3.7, 4.0, 4.5, 5.0, 6.0, 7.0, 8.0
NAVSEA-271:
- Set “A” consists of 28 I.Q.I.'s and contains the following sizes: .25 , .30, .35, .40, .45, .50, .60, .65, .70, .75, .80, .85, .90, 1.0, 1.1, 1.2, 1.3, 1.5, 1.6, 1.7, 1.8, 2.0, 2.1, 2.2, 2.3, 2.5
- Set “B” consists of 11 I.Q.I.'s and contains the following sizes: 2.7, 3.0, 3.2, 3.5, 3.7, 4.0, 4.5, 5.0, 6.0, 7.0, 8.0
ASME-SE-1025, ASTM-E-1025, API, AWS, AWWA:
- Set “A” consists of 25 I.Q.I.'s and contains the following sizes: #5, #6, #7 (or #8), #9, #10, #11, #12, #13, #15, #16, #17, #18, #20, #22, #25, #27, #30, #32, #35, #37, #40, #42, #45, #47, #50
- Set “B” consists of eleven I.Q.I.'s and contains the following sizes: #55, #60, #65, #70, #75, #80, #90, #100, #120, #140, #160
Penetrameter sets are available in the following materials:
Aluminum, Steel, Stainless Steel, Aluminum-Bronze, Brass, Copper, Cupro-Nickel, Inconel, Magnesium, Monel, Nickel, Phoshor-Bronze.
U.S.A.F. MASTER SET - ASTM-E-1742
Set includes the below sizes in;
Steel, Stainless Steel, Aluminum, Magnesium, Titanium
.12, .25, .37, .50, .62, .75, .87, 1.0, 1.2, 1.5, 1.7, 2.0, 2.2, 2.5, 2.7, 3.0
Copper
.12, .25, .37, .50, .62, .75, .87, 1.0
