| SyncScan 3 Phased Array Ultrasonic Flaw Detector w/ TFM & 4 Channel TOFD | UT-SIUI-SYNCSCAN3 |
|
Request Pricing | ||
Pratt & Whitney’s XRM document specifies step wedges conforming to TAM specs. TAM specs are tool numbers assigned to step wedges specifying material, width and length of the step wedge, step width, and step thicknesses.
| TAM # | Material | AMS # |
| 142395 | 6AL/ 4V Titanium |
4928 |
| 142396 | 303 Stainless Steel | 5640 |
| 142398 | Waspaloy | 5706 |
| 142398 | Inconel 718 | 5589 |
| 142399 | Haynes 25 | 5759 |
| 142939 | Hastelloy X | 5754 |
| 142939 | Inconel 600 | 5540 |
Material Verifications
Pratt & Whitney's XRM document specifies the requirement for dimensional and alloy verification. RAY-CHECK MFG. (RCM) verifies dimensions and issues an analytical report with I.Q.I's. RCM performs alloy verification in accordance with PWA MCL Sec. F-53 (thermo-electric testing).
Material certifications accompany alloy verification documents.
Aluminum and Magnesium alloys are sent out for semi-quantitative spectrographic analysis in accordance with PWA MCL Sec. F-23 and F-54.
| Number of Steps | 7 |
| Overall Width | 2 1/4" |
| Overall Length | 3 15/16" |
| Step Width | 9/16" |
| Step Thickness | .050", .075", .100", .125", .150", .200", .250" |
We have a discounted surplus P&W 7-Step Wedge available for purchase. Click the below link to see what we have in stock:
Note: Serialized radiographic products are not returnable
