Vidisco XBitPro
The specialized, proprietary software offers simple to operate yet highly advanced tools & processes for the ultimate image quality alongside user convenience.
Features:
| | - Acquires, enhances, analyzes and manages through a single all-inclusive software
- Minimal time & steps between you and getting the image you need
- Best one click tools to get clear visuals with minimal x-ray dose
- Easy to use image management
- Automatic processes for high quality images
- Multiple image formats
- 800% zoon
- Advanced stitching
- Automatic Wall Thickness Measurement, Statistics & Measurements
- First Image Restore option
|
The Vidisco Xbit Pro proprietary software offers the NDT operator sophisticated enhancement tools and user friendly data storage. These tools enable image grabbing, top-imaging analysis, documentation, data sharing and accurate results. NDT testing procedures can be easily repeated and high quality images are available immediately with advanced analysis tools to enable precise detection on the spot! Multi language GUI is available.
Vidisco XbitPro software and systems support current industrial standards such as BSS 7044, BSS 7075, ASTM E2422-05, ASME Boiler and Pressure Vessel Code, Section V, Article II, ASTM E2736 (including E2698 and E2737), ISO/DIS 17636-2 and ISO/DIS 10893-6.
Xbit Pro is included with all the Vidisco portable digital radiography systems: RayzorX Pro, FlashX Pro and BlazeXPro and the new BoltXPro and is compatible with all the Vidisco accessories.
|
800% Zoom
- 800% zoom exposes extra fine details
- Despite the enlargement, no digitizing effect
- Zoom in and out with a click of a button
|
Automatic Window Leveling - Enables viewing the full scale of 14-16 bit images ( on an 8bit computer screen)
- The raw image is not altered
- Optimum range generated in one click
|
Automatic Wall Thickness Measurement - Facilitates fast and exact (calibrated) multiple measurements
- Various macros can be saved for future re-use
- Tests are repeated easily and precisely
|
|
Automatic Subtraction - Automatically extracts differences between similar images
- Especially useful for detecting the slightest changes
- Detect change in materials, movement of parts and defects
|
Stitching - For fast automatic "sewing" together of images
- Merge images at the pixel level
- View large objects on one screen
- Save hours of work (no manual manipulation)
|
Slide Library - Slide Library Query
- Information is easily retrieved and shared
- Database management tools for convenient documentation
- Easily identify information such as location, X-ray conditions, category, project and more
|
|
Sharpening Algorithm - Sharpening enhances details in the image
- Images remain noise free
- Highest quality Unsharp Mask (edge enhancement)
|
Overlay Mode - Most advanced Overlay feature
- Enables viewing different exposure levels in layers on one screen
|
Proprietary Graphic & Processing Tools - Annotations
- Emboss, brightness and contrast
- Gamma correction
- Edge enhancing
|
|
Database Management - Comprehensive image information attached to Digital X-ray record
- Record location, imaging conditions, date, X-ray exposure and other details of RT during inspection with easy to use interface.
- DICOM compatible X-ray image saving
|
Adaptive Histogram - Easy viewing of materials with different densities
- Easily differentiate between piping under insulation, cables, or wires in cement.
- Enhanced viewing of small details
| |
